High-Performance SC-ST Patch Cord
SC to ST Patch Cord is a type of fiber optic cable that connects two optical connectors, one SC connector to one ST connector. They are used in a wide variety of applications, including telecommunications, data centers, and security systems.
- Hybrid Connectivity: Connects devices with SC and ST interfaces.
- Durable: Resists vibration and physical shock.
- Low Signal Loss: Ensures clean data transmission.
- Versatile: Ideal for data centers, telecom, and LANs.
- Reliable: 100% factory-tested to meet international standards.
Description
An SC-ST Patch Cord is a fundamental component for any robust and flexible fiber optic network, providing a reliable bridge between equipment with disparate connector interfaces. At EPCOM, we specialize in manufacturing high-quality fiber optic patch cords engineered for superior performance and durability. These cables are essential for linking modern network devices, which often use SC connectors, with existing infrastructure or specific equipment that utilizes the ST connector interface. Whether you are building a new data center, upgrading a telecommunications network, or managing enterprise-level LANs, our patch cords deliver the signal integrity and physical resilience your operations demand.
The design of our patch cords focuses on minimizing signal loss and ensuring a stable, long-lasting connection. By using premium materials and adhering to stringent manufacturing standards, EPCOM provides a solution that not only meets but exceeds industry benchmarks for performance. This commitment to quality ensures that your network maintains high-speed data transmission with minimal downtime, safeguarding your critical communications and data flow.
Understanding the SC-ST Patch Cord Design
The effectiveness of a hybrid patch cord lies in the specific attributes of its connectors. The combination of the SC and ST connectors offers a unique blend of modern convenience and rugged reliability, making it a versatile choice for a wide range of networking environments.
The SC Connector Advantage
The Subscriber Connector (SC) is renowned for its user-friendly design. Featuring a square-shaped body and a simple push-pull latching mechanism, it allows for quick and easy mating and de-mating. This design prevents rotational misalignment and ensures a consistent, low-loss connection every time. The SC connector is widely adopted in data communications and telecommunications applications, including passive optical networks (PON) and Gigabit Ethernet, due to its excellent performance and high packing density.
The ST Connector Advantage
The Straight Tip (ST) connector, on the other hand, is known for its robust and secure bayonet-style coupling. This spring-loaded, twist-and-lock mechanism provides a firm and reliable connection that is resistant to vibrations and physical shock. While it is more common in legacy systems, the ST connector remains a popular choice for industrial, military, and corporate networking environments where durability is a primary concern.
Why a Hybrid SC-ST Patch Cord is Essential
The primary function of an SC to ST fiber cable is to provide seamless interoperability. In many real-world scenarios, network technicians must integrate new hardware with existing systems. For instance, a new network switch with SC ports may need to connect to an established patch panel that uses ST ports. Our SC-ST patch cord facilitates this connection without requiring costly equipment overhauls, offering a practical and efficient solution for network expansion and maintenance.
Core Features and Benefits
EPCOM’s patch cords are built to deliver consistent, high-level performance. Each cable is meticulously crafted from high-grade components to ensure it meets the rigorous demands of modern fiber optic networks. We focus on three key areas: performance, durability, and application versatility.
- Superior Signal Integrity: Our cables are engineered for low insertion loss (IL) and high return loss (RL), which are critical for maintaining a strong and clear signal. Low IL means that very little signal power is lost through the connection, while high RL indicates that minimal signal is reflected back towards the source. This results in cleaner data transmission, especially over long distances.
- Exceptional Durability: Each cable features precision-polished ceramic ferrules that ensure precise fiber alignment and can withstand thousands of mating cycles. The outer jacket is available in various materials, including Riser (OFNR), Plenum (OFNP), and Low Smoke Zero Halogen (LSZH), to meet different fire safety and environmental requirements.
- Broad Application Versatility: These patch cords are ideal for a multitude of applications. They are commonly deployed in telecommunications closets, data centers, local area networks (LANs), and Fiber-to-the-Home (FTTH) setups. To learn more about the diverse applications of fiber optics, you can visit the Fiber Optic Association, a leading industry resource for education and standards.
Detailed Specifications for the SC-ST Patch Cord
All EPCOM products are subject to rigorous quality control to guarantee they meet or exceed international standards. Below are the detailed technical specifications for our SC to ST fiber optic patch cord.
| Technical Specifications | |
|---|---|
| Fiber Mode | Single-mode (G652D, G657A1/A2), Multi-mode (OM1, OM2, OM3, OM4, OM5) |
| Connector Type | Connector A: SC; Connector B: ST |
| Polish Type | SC (UPC, APC), ST (UPC) |
| Insertion Loss | ≤0.3dB |
| Return Loss | SM UPC ≥50dB; SM APC ≥60dB; MM UPC ≥35dB |
| Cable Assembly | Simplex, Duplex |
| Cable Diameter | 2.0mm, 3.0mm |
| Jacket Material | Riser (OFNR), Plenum (OFNP), Low Smoke Zero Halogen (LSZH) |
| Jacket Color | Yellow (SM), Orange (OM1/OM2), Aqua (OM3), Magenta (OM4), Lime Green (OM5) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Compliance | Telcordia GR-326, IEC 61300, RoHS |
Installation and Maintenance Best Practices
Proper handling and maintenance are crucial for maximizing the lifespan and performance of your fiber optic patch cords. Always keep protective dust caps on the connectors when not in use to prevent contamination, which is a leading cause of network failure. Additionally, avoid bending the cable tighter than its specified bend radius to prevent micro-fractures in the fiber that can degrade the signal.
To maintain a pristine network, a complete set of tools is essential. For creating versatile connections between different cables, an ST Fiber Optic Adaptor can provide a secure and reliable link. Before making any connection, it is critical to ensure the connector end-faces are perfectly clean. Our Fiber Optic Cassette Cleaner is an indispensable tool for removing dust and oils that can obstruct the signal. After installation or during troubleshooting, you can verify network performance and power levels with a precise instrument like our MPO/MTP Optical Power Meter.
Why Choose EPCOM for Your Fiber Optic Needs
At EPCOM, we are dedicated to providing our clients with networking components that offer uncompromising quality and reliability. Our SC-ST patch cords are a testament to this commitment. Each cable undergoes 100% factory testing for insertion loss, return loss, and end-face integrity to ensure it meets our high standards. By partnering with EPCOM, you are choosing a supplier that understands the critical nature of your network and is invested in your success. Contact us today to discuss your specific requirements or to request a quote.
